Ranco ETC-211000-000 Electronic Temperature Control 2 Stages (-30 To 220f) 120/208-240v

Ranco ETC-211000-000 Electronic Temperature Control 2 Stages (-30 To 220f) 120/208-240v

Size Guide

Ranco ETC-211000-000 Electronic Temperature Control 2 Stages (-30 To 220f) 120/208-240v
The Ranco ETC Series Electronic Temperature Control offers a full-featured electronic replacement for electrical-mechanical temperature controls used in many commercial refrigeration applications.
With its wide temperature range, one and two stage capability, selectable heating/cooling modes and multi-voltage input, the ETC is designed to provide application flexibility.
Models available include 120/208/240V AC and 24V AC.
Anti-short cycle compressor delay for cooling applications
LCD read-out for sensor temperature, control settings, and relay status

Weight : 1.9 LBR
Volume : 0.0527728 FTQ
Model : ETC-211000-000
UPC-EAN : 662013924447

ETC-211000-000

ETC Series Electronic Controls

The Rancoreg; ETC Series Electronic Temperature Control offers a full-featured electronic replacement for electrical-mechanical temperature controls used in many commercial refrigeration applications. With its wide temperature range, one and two stage capability, selectable heating/cooling modes and multi-voltage input, the ETC is designed to provide application flexibility. Models available include 120/208/240V AC and 24V AC.

Features and Benefits

Anti-short cycle compressor delay for cooling applications
Wide temperature range (-30F to 220F) (-34.4C to 104.4C)
Wide differential adjustment (1F to 30F) (-17C to -1C)
LCD read-out for sensor temperature, control settings, and relay status
High Amp output relay (FLA 16 Amps @ 120V AC and 8 Amps @ 208/240V AC) single stage
EEPROM memory retains control settings during power outages
Keypad lockout to prevent end-user alteration of settings
8 foot lead with sensor is extendable up to 400 feet using 18 or 22-gauge thermostat wire
Easy 4-step set-up
Heavy-duty relay is 1 HP rated
Selectable deg;F or deg;C heating/cooling modes
Single and two stage models
NEMA 1 case and cover
NEMA 4X models available
White backlight on display
Sensor rated IP67 for dust and water (lt;1m) resistance

Reference G2204.ETC21100

Condition New

Data sheet

Product Feature: Anti-short cycle compressor delay for cooling applications
LCD read-out for sensor temperature, control settings, and relay status
Models available include 120/208/240V AC and 24V AC.
The Ranco ETC Series Electronic Temperature Control offers a full-featured electronic replacement for electrical-mechanical temperature controls used in many commercial refrigeration applications.
With its wide temperature range, one and two stage capability, selectable heating/cooling modes and multi-voltage input, the ETC is designed to provide application flexibility.
Weight: 1.9 LBR
Volume: 0.0527728 FTQ
Model: ETC-211000-000
UPC-EAN: 662013924447
Sales Unit: EA
Origin: Mexico
US Tariff Code: 9032.10.0090
Base Unit: EA
Dimensions: 7.0 x 5.0 x 9.0
