Danfoss NTZ271A3LR1A 9HP R404,R452, LBP Reciprocating Refrigeration Compressor 200-230/3/60 (V/Ph/Hz),Discharge 1-1/4 in V04, Suction 1-3/4 in V02, Rotolock,POE Oil,120F0285 Replaces LTZ100-3V,120F0292,NTZ271A3LR1A

Size Guide

Tags refrigeration compressor condensing unit compressor

Danfoss NTZ271A3LR1A 9HP R404,R452, LBP Reciprocating Refrigeration Compressor 200-230/3/60 (V/Ph/Hz),Discharge 1-1/4 in V04, Suction 1-3/4 in V02, Rotolock,POE Oil,120F0285 Replaces LTZ100-3V,120F0292,NTZ271A3LR1A
Maneurop reciprocating compressors from Danfoss Commercial Compressors are specially designed for applications with a wide range of operating conditions
NT and LTZ series compressors are of the hermetic reciprocating type and are designed for Medium and Low evaporating temperature applications
The positive benefits of internal motor protection, high efficiency circular valve design and high torque motors provide for a quality installation
NT and LTZ compressors have a large internal free volume that protects against the risk of liquid hammering when liquid refrigerant enters the compressor
These compressor ranges can be used with a large choice of refrigerants according their compatibility with the oil

Weight : 167.58 LBR
Volume : 4.314980469 FTQ
Model : NTZ271A3LR1A
UPC-EAN : 5702428935159

Reference G0315.100LTZ

Condition New

Data sheet

Product Feature: Maneurop reciprocating compressors from Danfoss Commercial Compressors are specially designed for applications with a wide range of operating conditions
NT and LTZ compressors have a large internal free volume that protects against the risk of liquid hammering when liquid refrigerant enters the compressor
NT and LTZ series compressors are of the hermetic reciprocating type and are designed for Medium and Low evaporating temperature applications
The positive benefits of internal motor protection, high efficiency circular valve design and high torque motors provide for a quality installation
These compressor ranges can be used with a large choice of refrigerants according their compatibility with the oil
Weight: 167.58 LBR
Volume: 4.314980469 FTQ
Model: NTZ271A3LR1A
UPC-EAN: 5702428935159
Sales Unit: EA
Origin: France
US Tariff Code: 8414.30.8070
Base Unit: EA
Dimensions: 15.75 x 25.59 x 18.5

Download

Data sheet

Download (116.68KB)
